Description
Technical
Specifications
Inputs / Outputs
| Inputs | 48 voies d'entrée (jusqu'à 56 selon configuration), préamplis micro télécommandés |
|---|
Processing
| Mix buses | 27 |
|---|
Surface
| Motorized faders | No |
|---|---|
| Touchscreen | No |
| Groups | Groupes VCA et POPulation pour la navigation par voies |
| Faders | Nombre de faders physiques à vérifier |
Recording
| Onboard recording | No |
|---|
Networking
| Networking & protocols | AES50 / MADI |
|---|---|
| Redundant PSU | No |
| Redundant networking | No |
Other
| Buses | 27 bus de mixage |
|---|---|
| Fx | 6 moteurs d'effets stéréo |
| Processing | Traitement virgule flottante 40 bits, latence gérée (managed latency) |
| Network | Réseau AES50 (SuperMAC) ; MADI via carte optionnelle |
Strip & details
Rotate your phone to landscape for a better view of the strip.
Accessories
Stagebox / rack
- Midas DL251 / DL252 Stagebox
AES50 stageboxes paired with the PRO Series to remote the I/O.
Editorial & artists
Our take
History & design
The Midas PRO3 is a digital live console (also usable in the studio) introduced in 2009, positioned as the compact, more affordable option in the PRO Series (alongside the PRO6 and PRO9). It offers 48 input channels (up to 56 depending on configuration) with remote-controlled mic preamps, 27 mix buses and six stereo effects engines. Like the whole PRO Series, it runs 40-bit floating-point processing with managed latency and provides VCA and POPulation groups. Network connectivity relies on AES50 (SuperMAC), with MADI available via optional card.
