Description
Technical
Specifications
Processing
| Mix buses | 80 |
|---|---|
| Architecture | Surface de contrôle + cœur de traitement déporté Centuri (ordinateur industriel SSL, DSP modulaire, cartes E/S) |
| Core | Cœur DSP/E-S centralisé Centuri : traitement et E/S regroupés dans un rack central, surface déportée |
| Mix Inputs | Plus de 500 entrées de mixage, jusqu'à 512 entrées depuis un seul cœur Centuri |
Surface
| Motorized faders | No |
|---|---|
| Touchscreen | No |
| Faders | Surface assignable évolutive de 8 à 96 faders |
| Multi Operator | Fonctionnement multi-opérateur (jusqu'à 3) |
Recording
| Onboard recording | No |
|---|
Networking
| Networking & protocols | MADI / AES/EBU |
|---|---|
| Redundant PSU | No |
| Redundant networking | No |
Other
| Channels | Jusqu'à 512 voies d'entrée et plus de 500 entrées de mixage depuis un seul cœur Centuri |
|---|---|
| Busses | 80 bus de mixage, formatage multicanal jusqu'au 7.1 |
| Daw | Contrôle HUI simultané de 4 stations audionumériques (DAW), accès conjoint voies console et pistes DAW |
| Post | 64 commutateurs PEC/Direct, matrice de monitoring 128 x 8, matrice de re-recording 32 x 16, contrôle série de magnétoscopes HD |
| Surround | Stéréo, 5.1, 7.1, Dolby ; 4 sorties monitoring 7.1 |
| Multiop | Capacité multi-opérateur véritable depuis un seul cœur de traitement |
| Audio | 96 kHz, synchronisation HD / Tri-Level |
Strip & details
Rotate your phone to landscape for a better view of the strip.
Documents
Editorial & artists
Our take
History & design
The SSL C300 HD Master Studio System is an assignable digital console dedicated to audio post-production for picture (film, television, advertising). Unveiled in 2007 as the HD evolution of the C300, it is built around the centralised Centuri core that groups DSP processing and the I/O matrix, with a remote, scalable control surface from 8 to 96 faders.
The system addresses over 500 mix inputs, 512 channels, 80 mix busses and natively handles multichannel formats up to 7.1. For picture work it integrates 64 PEC/Direct switches, a 128 x 8 monitor matrix, a 32 x 16 re-record matrix and serial control of HD VTRs. It simultaneously controls up to four DAWs via HUI emulation, bringing console paths and DAW tracks onto one surface, and allows multi-operator working from a single core.
