Description
Technical
Specifications
Inputs / Outputs
| Total inputs | 32 |
|---|---|
| Inputs / outputs | Up to 92 inputs / 90 outputs via REAC devices |
Processing
| Aux sends | 8 |
|---|---|
| Matrices | 4 |
| Max sample rate | 48 kHz |
| Bit depth | 24 bits |
| Channels | 32 mixing channels, 8 auxes, 4 matrices, main LCR output |
| Effects and plug-ins | Two REAC ports (RJ-45 EtherCon); works with Digital Snake stage boxes, M-48 and S-4000M · 4 multi-effects (11 types: reverb, delay, chorus, phaser...) |
| Conversion | 24-bit conversion, 44.1/48 kHz; typical network latency 2.8 ms |
| Channel processing | 8-band parametric EQ and delay on each aux/matrix/main output |
Surface
| Physical faders | 16 |
|---|---|
| Motorized faders | Yes |
| Touchscreen | No |
Recording
| Onboard recording | No |
|---|
Networking
| Networking & protocols | Network |
|---|---|
| Redundant PSU | No |
| Redundant networking | No |
Strip & details
Rotate your phone to landscape for a better view of the strip.
Rotate your phone to landscape for a better view of the strip.
Rotate your phone to landscape for a better view of the strip.
Rotate your phone to landscape for a better view of the strip.
Software
Other screenshots
Accessories
Other
- Roland M-48 Personal Mixer
REAC-networked personal monitor mixer, controllable from the M-300.
Documents
Editorial & artists
Our take
History & design
The Roland M-300 is a live digital mixing console in the V-Mixer range, sitting below the M-480. It offers 32 mixing channels, 8 auxes, 4 matrices and a main LCR output, with 24-bit conversion (44.1/48 kHz) and a typical network latency of 2.8 ms. Each aux, matrix and main output gets an 8-band parametric EQ and a delay; four multi-effects (eleven types) round out the processing.
Like the whole range, it relies on the REAC network: two RJ-45 EtherCon ports address up to 92 inputs and 90 outputs via stage boxes, and drive Digital Snake preamps, M-48 personal monitor mixers or an S-4000M merge unit. A complete, cascadable system in a small footprint.
